Durable Ratchet Tie Down Straps – Strong & Reliable for Transport

Short Description:

Product Detail

Product Tags

1. General Specifications

Parameter	Typical Value/Range
Type	Ratchet Tie-Down Strap
Material	Polyester/Nylon Webbing
Color	Yellow, Blue, Green, Black, etc.
Standards	EN 12195-2, DIN 76051, US DOT Regulations

2. Webbing Specifications

Feature	Details
Width	25 mm (1″), 50 mm (2″), 75 mm (3″), 100 mm (4″)
Thickness	1.5 mm – 3.5 mm
Tensile Strength	1,000 kg – 10,000 kg (varies by width & layers)
Elongation	≤ 7% at Working Load Limit (WLL)
UV Resistance	Yes (if treated)
Abrasion Resistance	High (double-stitched edges)

3. Ratchet Mechanism Specifications

Component	Details
Material	Steel (galvanized/powder-coated) or Zinc Alloy
Gear Type	Single or Double Pawl System
Max. Handle Force	~150 N (for easy operation)
Release Mechanism	Push-button or lever release

4. Hook Specifications

Type	Description
S-Hook	General-purpose, fits D-rings
Flat Hook	Low-profile, fits slots
Wire Hook	Light-duty, flexible
J-Hook	Heavy-duty, secure grip
Material	Steel (Grade 70 or higher)
Coating	Zinc-plated, powder-coated, or stainless steel

5. Load Capacity & Safety Ratings

Rating	Value
Working Load Limit (WLL)	500 kg – 5,000 kg per strap
Break Strength	2x – 4x WLL (e.g., 2,000 kg WLL = 8,000 kg break strength)
Safety Factor	2:1 to 4:1 (industry standard)

Key Considerations When Choosing a Lashing Belt:

✔ Load Capacity – Must exceed cargo weight.
✔ Strap Width – Wider = stronger (e.g., 2″ for light-duty, 4″ for heavy loads).
✔ Hook Type – Must match anchor points (e.g., S-hooks for D-rings).
✔ Ratchet Quality – Steel ratchets last longer than plastic ones.
✔ Standards Compliance – Check for EN/DOT markings for legal use.
